Style
|
Weave
|
Weight
g/m2
|
Fiber count
|
Fiber strength
|
Thickness
(mm)
|
Width
(mm)
|
Working temprature
|
||
|
Warp
|
Weft
|
Warp
|
Weft
|
||||||
|
MKS03
|
Twill 3/1
|
300±30
|
≥18±1
|
≥12±1
|
≥300
|
≥250
|
0.3±0.05
|
92±1
|
1000℃
|
|
MKS06
|
Satin 8HS
|
600±30
|
≥18±1
|
≥13±1
|
≥600
|
≥500
|
0.6±0.05
|
92±1
|
1000℃
|
|
MKS011
|
Satin 12HS
|
1100±50
|
≥18±1
|
≥13±1
|
≥1000
|
≥750
|
1.25±0.1
|
92±1
|
1000℃
|
|
MKS180
|
Plain
|
180±30
|
≥13±1
|
≥13±1
|
≥260
|
≥260
|
0.18±0.05
|
92±1
|
1000℃
|
| Feature: Light weight High strength High modulus up to 2000℃ heat resistance Fatigue resistance Corrosion resistance |
Application: Aerospace Wind power Marine Automobile decoration Sports equipment Medical machine |
| Carbon fiber Data sheet | ||||||||
| Style | Weave | Weight g/m2 | Fiber Type | Fiber Count(10mm) | Thickness(mm) | Width(mm) | ||
| Warp | Weft | Warp | Weft | |||||
| MKS-1K-120 | Plain / 2/2 Twill | 120 | 1K | 1K | 9 | 9 | 0.12 | 100-1500 |
| MKS-1K-140 | Plain / 2/2 Twill | 140 | 1K | 1K | 10.5 | 10.5 | 0.14 | 100-1500 |
| MKS-3K-160 | Plain / 2/2 Twill | 160 | 3K | 3K | 4 | 4 | 0.16 | 100-1500 |
| MKS-3K-P180 | Plain / 2/2 Twill | 180 | 3K | 3K | 4.5 | 4.5 | 0.16 | 100-1500 |
| MKS-3K-200 | Plain / 2/2 Twill | 200 | 3K | 3K | 5 | 5 | 0.2 | 100-1500 |
| MKS-3K-220 | Plain / 2/2 Twill | 220 | 3K | 3K | 6 | 6 | 0.22 | 100-1500 |
| MKS-3K-240 | Plain / 2/2 Twill | 240 | 3K | 3K | 6 | 6 | 0.24 | 100-1500 |
| MKS-3K-280 | Plain / 2/2 Twill | 280 | 3K | 3K | 7 | 7 | 0.26 | 100-1500 |
| MKS-6K-320 | Plain / 2/2 Twill | 320 | 6K | 6K | 4 | 4 | 0.32 | 100-1500 |
| MKS-6K-360 | Plain / 2/2 Twill | 360 | 6K | 6K | 4.5 | 4.5 | 0.36 | 100-1500 |
| MKS-12K-320 | Plain / 2/2 Twill | 320 | 12K | 12K | 2 | 2 | 0.32 | 100-1500 |
| MKS-12K-400 | Plain / 2/2 Twill | 400 | 12K | 12K | 2.5 | 2.5 | 0.4 | 100-1500 |
| MKS-12K-480 | Plain / 2/2 Twill | 480 | 12K | 12K | 3 | 3 | 0.48 | 100-1500 |
| MKS-12K-560 | Plain / 2/2 Twill | 560 | 12K | 12K | 3.5 | 3.5 | 0.56 | 100-1500 |
