| Cell length （mm） | Density(kg/m3) | Plate compression strength | Plate shear strength | |||
| Pure core materials | Strength-L | Strength-W | Modulus-L | Modulus-W | ||
| 1.83 | 32 | 0.64 | 0.68 | 0.41 | 36 | 20 |
| 1.83 | 48 | 1.93 | 1.1 | 0.7 | 54 | 28 |
| 1.83 | 72 | 4.26 | 2.18 | 1.26 | 78 | 51 |
| 1.83 | 144 | 14.96 | 3.35 | 2.04 | 133 | 102 |
| 2.75 | 32 | 0.7 | 0.62 | 0.37 | 24 | 16 |
| 2.75 | 48 | 1.95 | 1.12 | 0.65 | 58 | 26 |
| 3.67 | 48 | 2.35 | 1.18 | 0.69 | 50 | 28 |
| 5.5 | 40 | 1.75 | 0.91 | 0.53 | 40 | 24 |
| Feature: Light weight High strength High modulus up to 2000℃ heat resistance Fatigue resistance Corrosion resistance |
Application: Aerospace Wind power Marine Automobile decoration Sports equipment Medical machine |
| Carbon fiber Data sheet | ||||||||
| Style | Weave | Weight g/m2 | Fiber Type | Fiber Count(10mm) | Thickness(mm) | Width(mm) | ||
| Warp | Weft | Warp | Weft | |||||
| MKS-1K-120 | Plain / 2/2 Twill | 120 | 1K | 1K | 9 | 9 | 0.12 | 100-1500 |
| MKS-1K-140 | Plain / 2/2 Twill | 140 | 1K | 1K | 10.5 | 10.5 | 0.14 | 100-1500 |
| MKS-3K-160 | Plain / 2/2 Twill | 160 | 3K | 3K | 4 | 4 | 0.16 | 100-1500 |
| MKS-3K-P180 | Plain / 2/2 Twill | 180 | 3K | 3K | 4.5 | 4.5 | 0.16 | 100-1500 |
| MKS-3K-200 | Plain / 2/2 Twill | 200 | 3K | 3K | 5 | 5 | 0.2 | 100-1500 |
| MKS-3K-220 | Plain / 2/2 Twill | 220 | 3K | 3K | 6 | 6 | 0.22 | 100-1500 |
| MKS-3K-240 | Plain / 2/2 Twill | 240 | 3K | 3K | 6 | 6 | 0.24 | 100-1500 |
| MKS-3K-280 | Plain / 2/2 Twill | 280 | 3K | 3K | 7 | 7 | 0.26 | 100-1500 |
| MKS-6K-320 | Plain / 2/2 Twill | 320 | 6K | 6K | 4 | 4 | 0.32 | 100-1500 |
| MKS-6K-360 | Plain / 2/2 Twill | 360 | 6K | 6K | 4.5 | 4.5 | 0.36 | 100-1500 |
| MKS-12K-320 | Plain / 2/2 Twill | 320 | 12K | 12K | 2 | 2 | 0.32 | 100-1500 |
| MKS-12K-400 | Plain / 2/2 Twill | 400 | 12K | 12K | 2.5 | 2.5 | 0.4 | 100-1500 |
| MKS-12K-480 | Plain / 2/2 Twill | 480 | 12K | 12K | 3 | 3 | 0.48 | 100-1500 |
| MKS-12K-560 | Plain / 2/2 Twill | 560 | 12K | 12K | 3.5 | 3.5 | 0.56 | 100-1500 |
