For Filament Winding/Pultrusion 1200 /2400 / 4800 Tex of Direct Fiber Glass Roving

Model NO.:EDR24-2400-386T/4800-386T
Description Review

Product Descrption

Direct Roving for Filament winding, is compatible with unsaturated polyester, polyurethane, vinyl ester, epoxy and phenolic resins. Main uses include manufacture of FRP pipes of various diameters, high-pressure pipes for petroleum transitions, pressure vessels, storage tanks, rebar and, insulation materials such as utility rods and insulation tube.

Product Features

1. Excellent package transfer
2. Good processing characteristics
3. Fast wet out in thermoset resin systems
4. Provides strand hardness without sacrificing rapid and complete wet-out
5. Low fuzz


Used to produce pipes of various diameters, storage tanks and tubes which are widely used in transportation, aerospace, military and electrical markets


Technical Data

Code Density(tex) Moisture content(%) Size content (%) Breakage strength (N/tex) Net weight(kg)
EDR-1200 1200 Less 0.10 0.55±0.15 ≥0.40 ≥13.0
EDR-2400 2400 Less 0.10 0.55±0.15 ≥0.40 ≥13.0
EDR-4400 4400 Less 0.10 0.55±0.15 ≥0.40 ≥13.0
EDR-4800 4800 Less 0.10 0.55±0.15 ≥0.40 ≥13.0
EDR-9600 9600 Less 0.10 0.55±0.15 ≥0.40 ≥13.0
