Description
Glass woven rovings are bidirectional fabric made by direct rovings in plain weave pattern.
Compatible with unsaturated polyester,vinyl resin,epoxy resin.
Applicable for hand lay-up,winding and compress molding process,suitable for manufacturing tank,boat,antomobile parts and other FRP products.
Reinforced Fiberglass Cloth is made of high strength E glass fiberglass yarn, with plain or twill weaving style. It is widely used in aircraft and spaceflight industry, ship industry, chemical industry, medical industry, military industry and sports goods, etc. It can be used to produce golf pole, surfboard, sailboard, boat hull, FRP tank, swimming pools, car bodies, FRP pipe as well as other FRP products.
600g E-glass Fiberglass Woven Roving is a woven material available in various sizes to allow custom strength, thickness, and weight in projects. Fiberglass cloth provides great strength and durability when layered with a resin to form a hardened composite.
Specification
| Style | Yarn(tex) | Density(ends/10cm) | Mass(g/m2) | Width(cm) | Tensile Strength(N/50mm) | ||
| Warp | Weft | Warp | Weft | ||||
| EWR200 | 200 | 50 | 50 | 200±16 | 90/100 | ≥1300 | ≥1100 |
| EWR400 | 600 | 35 | 32 | 400±32 | 100/127 | ≥2500 | ≥2200 |
| EWR570 | 1150 | 26 | 24 | 570±45 | 100/127 | ≥3600 | ≥3300 |
| EWR600 | 1200 | 26 | 24 | 600±48 | 100/127 | ≥4000 | ≥3850 |
| EWR800 | 2400 | 18 | 16 | 800±64 | 100/127 | ≥4600 | ≥4400 |
| CWR400 | 500 | 40 | 40 | 400±32 | 90/100 | ≥2000 | ≥1900 |
| CWR600 | 1200 | 26 | 24 | 600±48 | 100/127 | ≥2750 | ≥2600 |
| CWR800 | 2400 | 18 | 16 | 800±64 | 100/127 | ≥3000 | ≥2900 |
