E-glass Yarn Test Report
|
Name |
E-glass Yarn |
||
|
Supplier-code No: |
EC5.6 6.2 1*0 S80 |
||
|
glass type |
E glass R2O≤0.8% |
||
|
product Standard |
GB/T 18371-2008 |
||
|
Examine Items |
Standard |
Examine result |
Result |
|
Appearance |
Pure white,no stain |
Pure white, no stain |
qualified |
|
Filament diameter, um |
5.8±0.3 |
5.7 |
qualified |
|
Yarn Density,tex |
6.2±0.5 |
6.2 |
qualified |
|
Tensile Strength,N/tex |
Min0.38 |
0.4 |
qualified |
|
Twist,T/m |
80±5 |
78 |
qualified |
|
Loss on ignition,% |
1.1±0.20 |
1.2 |
qualified |
|
Moisture content,% |
Max.0.25 |
0.18 |
qualified |
Application: For Insulation of electrical winding wires.
